R-Unit Controller Series CE0272-1A (2020AUG)

Description

Cat #: CE0272-1A (2020AUG)
Pages: 80

This series of unit-connecting controllers allows you to freely select and combine connected actuators and control methods.
– Unit-connecting controllers support a wide array of combinations!
– Use the same driver units.
– Saves space inside the control panel.

The PDF version is downloadable from here.

Models

Gateway units (Positioner type):
(For situations where the stop position will be registered in the position data, and then the position number will be specified for operation.)
RCON-GWG-CC (CC-Link)
RCON-GWG-CIE (CC-Link IE Field)
RCON-GWG-DV (DeviceNet)
RCON-GWG-EC (EtherCAT)
RCON-GWG-EP (EtherNet/IP)
RCON-GWG-PR (PROFIBUS-DP)
RCON-GWG-PRT (PROFINET IO)

Program type:
(For situations where Cartesian coordinate system operation is performed for multiple axes combining single axes.)
RSEL-G-E
RSEL-G-NP (NPN PIO specification)
RSEL-G-PN (PNP PIO specification
RSEL-G-CC (CC-Link)
RSEL-G-CIE (CC-Link IE Field)
RSEL-G-DV (DeviceNet)
RSEL-G-EC (EtherCAT)
RSEL-G-EP (EtherNet/IP)
RSEL-G-PR (PROFIBUS-DP)
RSEL-G-PRT (PROFINET IO)

ELECYLINDER Unit:
(For situations where ELECYLINDER with ACR option is operated over a fieldbus.)
REC-GW-CC (CC-Link)
REC-GW-CIE (CC-Link IE Field)
REC-GW-DV (DeviceNet)
REC-GW-EC (EtherCAT)
REC-GW-EP (EtherNet/IP)
REC-GW-PR (PROFIBUS-DP)
REC-GW-PRT (PROFINET IO)
