Description
Cat #: CE0273-2A (2020AUG)
Pages: 32
Compared to the conventional pulse motor model this large slider type has a longer stroke and operates at higher speeds.
– Maximum stroke 2500mm.
– Maximum speed 2000m/s.
– Maximum payload 108kg.
– Standard-equipped with battery-less absolute encoder.
– Compatible with wireless teaching.
– Motor drive DC power unit can supply power for up to 6 axes.
The PDF version is downloadable from here.
Large Slider Type:
Applicable Controllers:
(Note) The EC series is equipped with a built-in controller.
The 200v motor power unit “PSA-200” is required for EC-S13/S13X/S15/S15X models to operate.
